The QCIT machine has reasonable design and structure, touch screen human-machine interface, PLC digital program control, coding and sizing, high degree of automation, smooth process, good product quality, stable mechanical performance, high yield, labor-saving and time-saving, and high overall linkage sizing accuracy.
6 tons of single arm uncoiling--feed guide centering--16-channel forming host--straightening device--servo tracking fixed-length hydraulic shearing--discharge table--control system--C-shaped U-shaped combined roller Roll forming die. It is composed of machine base, discharge shaft, holding plate, hydraulic expansion mechanism, expansion plate, pressing frame, hydraulic pressing arm, polyurethane pressing wheel, pressing motor and brake.
Equipment composition: front and rear steering device, outer cage and inner cage, storage tray, pinch feeder, gear box, length measuring, photoelectric detection element, electronic control console, hydraulic station (included in the shear butt welding hydraulic station system ).
